CF-G/CF-D Series
CF-ATTS
Forklift attachment bale clamp can handle various soft packs such as cotton, textile, wool, pulp, waste paper，hay and industrial scrap and other soft items for paper making, chemical fiber, waste paper recycling, port and other industries without pallet handling and stacking operations in a safe and efficient way.
Model | Capacity (kg/mm) | Mounting Class | Opening Range (mm) | Arm Length (mm) | Weight (kg) | ET(mm) |
BC-1.9TD-S1730-01 | 1900/500 | II | 450-1730 | 1000 | 420 | 125 |
BC-1.9TD-S1730-02 | 1900/500 | II | 450-1730 | 1200 | 465 | 125 |
BC-2.7TD-S1910-01 | 2700/500 | II/III | 560-1910 | 1000 | 555 | 140 |
BC-2.7TD-S1910-02 | 2700/500 | II/III | 560-1910 | 1200 | 625 | 140 |
BC-2.7TD-S1910-03 | 2700/500 | II/III | 560-1910 | 1350 | 680 | 150 |
BC-2.7TD-S1910-04 | 2700/500 | II/III | 560-1910 | 900 | 535 | 140 |
BC-2.7TD-S2300-01 | 2200/500 | III | 490-2300 | 1000 | 710 | 150 |
BC-2.7TD-S2300-02 | 2200/500 | III | 490-2300 | 1200 | 730 | 150 |
BC-3.2TD-S2100-01 | 3200/600 | III/IV | 570-2100 | 1220 | 940 | 175 |
BC-3.2TD-S2100-02 | 3200/600 | III/IV | 570-2100 | 1350 | 990 | 175 |
BC-3.2TD-S2100-03 | 3200/600 | III/IV | 570-2100 | 1500 | 1050 | 175 |
Forklift attachment bale clamp can handle various soft packs such as cotton, textile, wool, pulp, waste paper，hay and industrial scrap and other soft items for paper making, chemical fiber, waste paper recycling, port and other industries without pallet handling and stacking operations in a safe and efficient way.
Model | Capacity (kg/mm) | Mounting Class | Opening Range (mm) | Arm Length (mm) | Weight (kg) | ET(mm) |
BC-1.9TD-S1730-01 | 1900/500 | II | 450-1730 | 1000 | 420 | 125 |
BC-1.9TD-S1730-02 | 1900/500 | II | 450-1730 | 1200 | 465 | 125 |
BC-2.7TD-S1910-01 | 2700/500 | II/III | 560-1910 | 1000 | 555 | 140 |
BC-2.7TD-S1910-02 | 2700/500 | II/III | 560-1910 | 1200 | 625 | 140 |
BC-2.7TD-S1910-03 | 2700/500 | II/III | 560-1910 | 1350 | 680 | 150 |
BC-2.7TD-S1910-04 | 2700/500 | II/III | 560-1910 | 900 | 535 | 140 |
BC-2.7TD-S2300-01 | 2200/500 | III | 490-2300 | 1000 | 710 | 150 |
BC-2.7TD-S2300-02 | 2200/500 | III | 490-2300 | 1200 | 730 | 150 |
BC-3.2TD-S2100-01 | 3200/600 | III/IV | 570-2100 | 1220 | 940 | 175 |
BC-3.2TD-S2100-02 | 3200/600 | III/IV | 570-2100 | 1350 | 990 | 175 |
BC-3.2TD-S2100-03 | 3200/600 | III/IV | 570-2100 | 1500 | 1050 | 175 |
