Galvanised Spring Pallet Elevator with Pallet Truck Base

Equipped with forklift pockets for easy relocation
Availability:
Quantity:
  • CFP2000

  • CF-ATTS

· The pallet elevator keeps the active layer of the load at or above waist height, eliminating bending and lifting.

· This pallet elevator can be moved with a standard Pallet Truck

· It is proving highly effective at reducing the incidences of repetitive strain and back injury.

· The construction of the pallet elevator is a scissor type action with varying springs which can be adjusted for different heights

· Turntable allows the operator to rotate the load with minimal stretching and reaching.

· No ground fixing required

· Galvanised Finish

· Load Capacity: 2000kg

· Table Diameter: 1110mm

· Low Height: 290mm

· Max Height: 750mm

· Fork Pocket Centres: 615mm

· Fork Pocket Size: 300x90mm

· Unit Weight: 195kg
